3.3SMSR-2-BT/BF - Spring Isolator/Restrainer
SMSR-2-BT / BF spring mounts are designed to provide efficient isolation from critical vibrations and all-directional restraint from vertical and horizontal forces, as well as from forces due to seismic activities and high wind loads.
There are two available configurations:
- SMSR-2-BT: bolted top with leveling adjustment feature;
- SMSR-2-BF: flat top and inside leveling adjustment feature;
Recommended for:
HVAC equipment, fan air circulation systems, compressors, pumps, chillers, AC units, cooling towers, inertia bases, etc.
Features:
All springs at rated loads have 50% additional travel to solid load.
All mounts' elements are safe at solid load.
Safety factor - Springs will accommodate 50% extra load from rated load to solid load.
Recommended load range: from 50% of rated load to rated load.
Zinc plated housing provides good corrosion resistance.
Elastomer base & top cup provide better vibration isolation, load distribution, and noise reduction.
Springs are color-coded for easy field identification.
Anti-skid rubber acoustical pad is optional.
Click Here for Seismic Restrained Spring Mounts:
Please contact us for larger volume orders as further discounts may apply.
| Model | Rated Load (lbs) | Deflection at Rated Load (in) | Spring Rate (lbs/in) | Max. Vertical G Rating | Max. Horizontal G Rating | Spring Colour | Shipping Weight (lbs) | Price | Type | Quantity | Total | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1'' DEFLECTION | ||||||||||||
| SMSR-2-302 | 390 | 1 | 390 | Yellow | 31 | Inquire | ||||||
| SMSR-2-303 | 800 | 1 | 800 | Orange | 31 | Inquire | ||||||
| SMSR-2-304 | 1,060 | 1 | 1,060 | Red | 31 | Inquire | ||||||
| SMSR-2-303-311 | 1,300 | 1 | 1,300 | Orange/Green | 33 | Inquire | ||||||
| SMSR-2-305 | 1,650 | 1 | 1,650 | White | 31 | Inquire | ||||||
| SMSR-2-306 | 2,000 | 1 | 2,000 | Brown | 31 | Inquire | ||||||
| SMSR-2-306-311 | 2,400 | 1 | 2,400 | Brown/Green | 33 | Inquire | ||||||
| SMSR-2-305-312 | 2,800 | 1 | 2,800 | White/Yellow | 33 | Inquire | ||||||
| SMSR-2-307 | 3,400 | 1 | 3,400 | Green | 31 | Inquire | ||||||
| SMSR-2-308 | 4,000 | 1 | 4,000 | Black | 31 | Inquire | ||||||
| SMSR-2-307-312 | 4,660 | 1 | 4,660 | Green/Yellow | 33 | Inquire | ||||||
| SMSR-2-309 | 5,200 | 1 | 5,200 | Blue | 31 | Inquire | ||||||
| SMSR-2-308-313 | 5,980 | 1 | 5,980 | Black/Orange | 33 | Inquire | ||||||
| SMSR-2-308-314 | 6,500 | 1 | 6,500 | Black/Grey | 33 | Inquire | ||||||
| SMSR-2-309-314 | 7,700 | 1 | 7,700 | Blue/Grey | 33 | Inquire | ||||||
| 2'' DEFLECTION | ||||||||||||
| SMSR-2-350 | 160 | 2 | 80 | Plated | 32 | $190.00 |
| |||||
| SMSR-2-350-140 | 300 | 2 | 150 | Plated/Plated | 34 | $190.00 |
| |||||
| SMSR-2-352 | 360 | 1.8 | 200 | Plated | 32 | $190.00 |
| |||||
| SMSR-2-402 | 400 | 2 | 250 | Grey | 32 | Inquire | ||||||
| SMSR-2-352-140 | 500 | 1.8 | 250 | Plated/Plated | 34 | $200.00 |
| |||||
| SMSR-2-403 | 696 | 2 | 348 | Black | 32 | $220.00 |
| |||||
| SMSR-2-404 | 906 | 2 | 453 | Blue | 32 | $220.00 |
| |||||
| SMSR-2-405 | 1,180 | 2 | 590 | Red | 32 | $220.00 |
| |||||
| SMSR-2-406 | 1,352 | 2 | 676 | Orange | 32 | $220.00 |
| |||||
| SMSR-2-407 | 1,574 | 2 | 787 | Green | 32 | $220.00 |
| |||||
| SMSR-2-408 | 1,836 | 2 | 918 | White | 32 | $220.00 |
| |||||
| SMSR-2-409 | 2,000 | 2 | 1,000 | Brown | 32 | $220.00 |
| |||||
| SMSR-2-410 | 2,500 | 2 | 1,250 | Yellow | 32 | $220.00 |
| |||||
| SMSR-2-407-150 | 3,174 | 2 | 1,587 | Green/Grey | 34 | $240.00 |
| |||||
| SMSR-2-409-150 | 3,600 | 2 | 1,800 | Brown/Grey | 34 | $240.00 |
| |||||
| SMSR-2-410-150 | 4,100 | 2 | 2,050 | Yellow/Green | 34 | $240.00 |
| |||||
| 3'' DEFLECTION | ||||||||||||
| SMSR-2-601 | 280 | 3 | 93 | Blue | 33 | $380.00 USD |
| |||||
| SMSR-2-602 | 400 | 3 | 133 | Yellow | 33 | $380.00 USD |
| |||||
| SMSR-2-603 | 600 | 3 | 200 | Orange | 33 | $380.00 USD |
| |||||
| SMSR-2-604 | 900 | 3 | 300 | Red | 33 | $380.00 USD |
| |||||
| SMSR-2-605 | 1,200 | 3 | 400 | Green | 33 | $380.00 USD |
| |||||
| SMSR-2-604-660 | 1,500 | 3 | 500 | Red/Grey | 35 | Inquire | ||||||
| SMSR-2-605-660 | 1,800 | 3 | 600 | Green/Grey | 35 | Inquire | ||||||
Note: When product price is not shown, please call our office for technical consultation prior to place an order
Notes:
a) 350 Spring: 3” Outside diameter x 5” Free Length.
b) 300 Spring: 3” Outside diameter x 4.75” Free Length.
c) 400 Spring: 3” Outside diameter x 5.75” Free Length.
d) 600 Spring: 3” Outside diameter x 6.75” Free Length.
e) Rated load is the maximum load recommended.
