2.9MWT-2 Spring Isolator/Restrainer

MWT-2 series are heavy-duty seismic restrained spring mounts designed to withstand lateral loads in combination with vertical loads.

Recommended load range: from 50% of the maximum load to the maximum load of the spring isolator listed in the table below.

Recommended for vibration isolation of:

HVAC equipment, engine-generators (gensets), fan air circulation systems, compressors, pumps, chillers, AC units, cooling towers, inertia bases, etc.

MWT-2

MWT-2: Overall dimensions

Printable Pages:

Printable page: MWT-2

Installation instructions: MWT-2

STEP file: MWT-2

Features:

Safety Factor: Springs will accommodate an additional 50% load from the rated load to the solid load.

All spring mounts' elements are safe at solid load.

Interlocking steel channels restrict the movements (snubbers) in all horizontal directions.

Rubber lining inside metal channels prevents metal-to-metal contact.

Limit stops prevent vertical movement due to wind and seismic activity (see installation instructions for details).

Powder-coating of the housing and springs provides excellent corrosion resistance.

Acoustic elastomer spring cups provide superior vibration isolation and noise reduction.

Springs are color-coded and easily replaceable.

Includes a bottom anti-skid rubber acoustical pad; the top rubber pad is optional.

Go here for Seismic Restrained Isolators:

Please contact us for larger volume orders as further discounts may apply.

Model	Rated Load (lbs)	Deflection at Rated Load (in)	Spring Rate (lbs/in)	Spring Colour	Shipping Weight (lbs)
1'' DEFLECTION
MWT-2-302	390	1	390	Yellow	52	Inquire
MWT-2-303	800	1	800	Orange	52	Inquire
MWT-2-304	1,060	1	1,060	Red	52	Inquire
MWT-2-303-311	1,300	1	1,300	Orange/Green	54	Inquire
MWT-2-305	1,650	1	1,650	White	52	Inquire
MWT-2-306	2,000	1	2,000	Brown	52	Inquire
MWT-2-306-311	2,400	1	2,400	Brown/Green	54	Inquire
MWT-2-305-312	2,800	1	2,800	White/Yellow	54	Inquire
MWT-2-307	3,400	1	3,400	Green	52	Inquire
MWT-2-308	4,000	1	4,000	Black	52	Inquire
MWT-2-307-312	4,660	1	4,660	Green/Yellow	54	Inquire
MWT-2-309	5,200	1	5,200	Blue	52	Inquire
MWT-2-308-313	5,980	1	5,980	Black/Orange	54	Inquire
MWT-2-308-314	6,500	1	6,500	Black/Grey	54	Inquire
MWT-2-309-314	7,700	1	7,700	Blue/Grey	54	Inquire
2'' DEFLECTION
MWT-2-350	160	2	80	Plated	54	Inquire
MWT-2-350-140	300	2	150	Plated/Plated	56	Inquire
MWT-2-352	360	2	200	Plated	54	Inquire
MWT-2-402	400	2	200	Grey	54	Inquire
MWT-2-352-140	500	2	277	Plated/Plated	56	Inquire
MWT-2-403	696	2	348	Black	54	Inquire
MWT-2-404	906	2	453	Blue	54	Inquire
MWT-2-405	1,180	2	590	Red	54	Inquire
MWT-2-406	1,352	2	676	Orange	54	Inquire
MWT-2-407	1,574	2	787	Green	54	Inquire
MWT-2-408	1,836	2	918	White	54	Inquire
MWT-2-409	2,000	2	1,000	Brown	54	Inquire
MWT-2-410	2,500	2	1,250	Yellow	54	Inquire
MWT-2-407-150	3,174	2	1,587	Green/Grey	56	Inquire
MWT-2-409-150	3,600	2	1,800	Brown/Grey	56	Inquire
MWT-2-410-150	4,100	2	2,050	Yellow/Grey	56	Inquire
3" DEFLECTION
MWT-2-601	200	3	93.3	Blue	56	Inquire
MWT-2-602	400	3	133.3	Yellow	56	Inquire
MWT-2-603	600	3	200	Orange	56	Inquire
MWT-2-604	900	3	300	Red	56	Inquire
MWT-2-605	1,200	3	400	Green	56	Inquire
MWT-2-604-660	1,500	3	500	Red/Grey	58	Inquire
MWT-2-605-660	1,800	3	600	Green/Grey	58	Inquire

Note: When product price is not shown, please call our office for technical consultation prior to place an order

Notes:

a) 300 Spring: 3” Outside diameter x 4.75” Free Length.

b) 400 Spring: 3” Outside diameter x 5.75” Free Length.

c) 600 Spring: 3” Outside diameter x 6.75” Free Length.

d) Rated load is the maximum load recommended.
