1.6FSM/SM Channel & Sandwich Vibration Dampers
FSM/SM are versatile, anti-vibration channel mounts/dampers that allow the top and bottom plates to be drilled anywhere along their length.
The plates are bonded together with oil-resistant neoprene elastomer.
Recommended use in vibration isolation of:
- Wall and ceiling installations where a channel can be used as a mounting rail.
- Small-cut blocks can be used as individual isolators.
Custom:
- Material: aluminum or stainless steel.
- Other elastomer materials/compounds available on request.
- Upon request can be cut to any length required.
Features:
Low installation height.
Superior ability to withstand shear load with low horizontal deflection.
Effectively isolates against horizontal, vertical, and shock forces.
Click Here For Rubber Isolators:
Please contact us for larger volume orders as further discounts may apply.
| Model | Linear Load (lbs/in) | Length (in) | W (in) | H (in) | T (in) | A (in) | B (in) | C (in) | Price | Quantity | Total | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FSM | ||||||||||||
| FSM-12 | 50 | 12 | 4-1/2 | 1-5/16 | 3/4 | 1-1/2 | 1 | $110.00 USD |
| |||
| FSM-24 | 50 | 24 | 4-1/2 | 1-5/16 | 3/4 | 1-1/2 | 1 | $200.00 USD |
| |||
| FSM-48 | 50 | 48 | 4-1/2 | 1-5/16 | 3/4 | 1-1/2 | 1 | $360.00 USD |
| |||
| FSM-60 | 50 | 60 | 4-1/2 | 1-5/16 | 3/4 | 1-1/2 | 1 | $470.00 USD |
| |||
| SM | ||||||||||||
| SM-1-12 | 300 | 12 | 2 | 1-3/4 | 5/16 | $90.00 USD |
| |||||
| SM-1-24 | 300 | 24 | 2 | 1-3/4 | 5/16 | $180.00 USD |
| |||||
| SM-1-48 | 300 | 48 | 2 | 1-3/4 | 5/16 | $260.00 USD |
| |||||
| SM-2-12 | 450 | 12 | 3 | 2 | 3/8 | $120.00 USD |
| |||||
| SM-2-24 | 450 | 24 | 3 | 2 | 3/8 | $220.00 USD |
| |||||
| SM-2-48 | 450 | 48 | 3 | 2 | 3/8 | $360.00 USD |
| |||||
| SM-3-12 | 600 | 12 | 4 | 2-5/16 | 1/2 | $140.00 USD |
| |||||
| SM-3-24 | 600 | 24 | 4 | 2-5/16 | 1/2 | $260.00 USD |
| |||||
| SM-3-48 | 600 | 48 | 4 | 2-5/16 | 1/2 | $480.00 USD |
| |||||
Note: When product price is not shown, please call our office for technical consultation prior to place an order
We apologise for the inconvenience but this product is currently unavailable online. Please contact us directly to place your order
